2 channels GaN class D power amplfier

2 channels GaN class D power amplfier
Availability:
Quantity:
Inquire Add to Basket

  • DG220/DG222/DG225/DG230/DG235/DG242/DG260

  • KET

Model No. DG222DG225DG230DG235DG242
8Ω Stereo Output Power 2200W2500W3000W3500W4200W
4Ω Stereo Output Power4180W4400W5100W6500W7800W
2Ω Stereo Output Power5225W5500W7140W7500W8500W
8Ω Bridge watts7600W8800W10200W13000W15600W
4Ω Bridge watts10000W11000W14280W15000W17000W
Output CircuitD
Height 1U
Frequency response 20Hz-20kHz,+0/-1dB
THD+N <0.5%,20Hz-20kHz
IMD <0.05%
Slew Ratio50 V/µs @ 8 Ω
Damping factor >5000 @ 20-200 Hz
S/N Ratio >110dB
Gain selection 32dB/35dB/38DB/41dB
Input connectorXLR
Output connector Speakon
Front panel control AC Power Switch, LED(Pro/Clip), 2 channels volume
Rear panel control Input Mode Switch: MONO Bridge, CLIP ON, GAIN
Dimension483mmx45mmx450mm
