| Quantity: | |
|---|---|
| Model No. | DG418 | DG422 | DG430 | DG435 |
| 8Ω Stereo Output Power | 1800W | 2200W | 3000W | 3500W |
| 4Ω Stereo Output Power | 2925W | 3700W | 5000W | 5600W |
| 2Ω Stereo Output Power | 4000W | 5200W | 6500W | 7280W |
| 8Ω Bridge watts | 5400W | 6600W | 10000W | 10500W |
| 4Ω Bridge watts | 7800W | 9800W | 13000W | 14560W |
| Output Circuit | D | |||
| Height | 1U | |||
| Frequency response | 20Hz-20kHz,+0/-1dB | |||
| THD+N | <0.5%,20Hz-20kHz | |||
| IMD | <0.05% | |||
| Slew Ratio | 50 V/µs @ 8 Ω | |||
| Damping factor | >5000 @ 20-200 Hz | |||
| S/N Ratio | >110dB | |||
| Gain selection | 32dB/35dB/38DB/41dB | |||
| Input connector | XLR | |||
| Output connector | Speakon | |||
| Front panel control | AC Power Switch, LED(Pro/Clip), 4 channels volume | |||
| Rear panel control | Input Mode Switch: MONO Bridge, CLIP ON, GAIN | |||
| Dimension | 483mmx45mmx450mm | |||
| Model No. | DG418 | DG422 | DG430 | DG435 |
| 8Ω Stereo Output Power | 1800W | 2200W | 3000W | 3500W |
| 4Ω Stereo Output Power | 2925W | 3700W | 5000W | 5600W |
| 2Ω Stereo Output Power | 4000W | 5200W | 6500W | 7280W |
| 8Ω Bridge watts | 5400W | 6600W | 10000W | 10500W |
| 4Ω Bridge watts | 7800W | 9800W | 13000W | 14560W |
| Output Circuit | D | |||
| Height | 1U | |||
| Frequency response | 20Hz-20kHz,+0/-1dB | |||
| THD+N | <0.5%,20Hz-20kHz | |||
| IMD | <0.05% | |||
| Slew Ratio | 50 V/µs @ 8 Ω | |||
| Damping factor | >5000 @ 20-200 Hz | |||
| S/N Ratio | >110dB | |||
| Gain selection | 32dB/35dB/38DB/41dB | |||
| Input connector | XLR | |||
| Output connector | Speakon | |||
| Front panel control | AC Power Switch, LED(Pro/Clip), 4 channels volume | |||
| Rear panel control | Input Mode Switch: MONO Bridge, CLIP ON, GAIN | |||
| Dimension | 483mmx45mmx450mm | |||
