1. JK series tradition power amplifier have excellent continuous output capacity and provide us traditional excellent sound quality.
2. 2 channels 2U high-performance and multi-function design.
3. Perfect circuit protection design: power-on buffer, overheating protection, short circuit protection, pressure limit protection, over current protection, over load protection, output DC protection.
4. With cost-effective, highly reliable and unique high-grade design appearance is favored by the majority of customers.
5. Applications for indoor and outdoor: Entertainment or multimedia.
MODEL NO. | JK450B | JK600B | JK800B | JK1000B |
8Ω Stereo Output Power | 450W | 600W | 800W | 1000W |
4Ω Stereo Output Power | 650W | 800W | 1000W | 1350W |
8Ω Bridged watts | 1300W | 1750W | 2350W | 2950W |
Output Circuit | AB | H | H | H |
Height | 2U | |||
Frequency response | 20Hz-20KHz, +0/-1dB | |||
THD+N | <0.5%, 20Hz-20KHz | |||
S/N Ratio | >100dB | |||
Slew Ratio | >10v/us | |||
Damping factor | >200 | |||
Crosstalk | At 1kHz, -75dB; At 20kHz, -59dB | |||
Input sensitivity | 0.775V/1.4V | |||
Input impedance | 20KOhm(Balance)/10KOhm(Unbalance) | |||
Input connector | XLR, RCA | |||
Output connector | Binding posts, Speakon | |||
Front panel control | AC Power Switch, LED(Clip, Signal, Protect, Active),2 channels volume | |||
Rear panel control | Input Mode Switch: Stereo/Parallel/Bridge, Sensitivity | |||
Cooling | Variable Speed Fans,Front-To-Rear Airflow | |||
Dimension | 480mm * 320mm * 90mm | |||
Net weight | 12.55 KG | 13.05 KG | 13.55 KG | 14.05 KG |
Gross weight | 14.95 KG | 15.45 KG | 15.95 KG | 16.45 KG |
Packing dimension | 577mm * 558mm * 160mm | |||
