1. The most advanced class H circuit technology makes the output current more stronger and output more powerful.
2. Audio-specific ultra large pure copper high-quality toroidal transformer and ultra large capacity filter capacitor provide more than twice rated power and excellent charge and discharge speed.
3. Perfect circuit protection design: power-on buffer, overheating protection, short circuit protection, pressure limit protection, over current protection, over load protection, output DC protection.
4. With cost-effective, highly reliable，strong power and unique appearance design is favored by the majority of customers.
5. Applications for indoor and outdoor: KTV, Entertainment club, Stadium, Conference room etc.
| MODEL NO. | KB1200D |
| 8Ω Stereo Output Power | 4×1000W |
4Ω Stereo Output Power | 4×1500W |
8Ω Bridged watts | 2×3000W |
Output Circuit | H |
Height | 3U |
Frequency response | 5Hz-50KHz+/-0.5dB |
THD+N | <0.05%@8Ohm 1/3Po |
S/N Ratio | >102dB |
Slew Ratio | 40V/u S |
Damping factor | >400 |
Crosstalk | >65dB@8Ohm 1KHz |
Input sensitivity | 0.775V/1.0V/1.4V |
Input impedance | 20KOhm(Balance)/10KOhm(Unbalance) |
Input connector | Male XLR,Female XLR |
Output connector | Binding posts, Speakon |
Front panel control | AC Power Switch, LED(Protect,Clip ,Signal, Active),4 channels volume |
Rear panel control | Input Mode Switch: Stereo/Parallel/Bridge, Sensitivity |
Cooling | Variable Speed Fans,Front-To-Rear Airflow |
Dimension | 640mm * 480mm * 135mm |
Net weight | 38.85 kg |
Gross weight | 41.95 kg |
Packing dimension | 715mm * 555mm * 185mm |
1. The most advanced class H circuit technology makes the output current more stronger and output more powerful.
2. Audio-specific ultra large pure copper high-quality toroidal transformer and ultra large capacity filter capacitor provide more than twice rated power and excellent charge and discharge speed.
3. Perfect circuit protection design: power-on buffer, overheating protection, short circuit protection, pressure limit protection, over current protection, over load protection, output DC protection.
4. With cost-effective, highly reliable，strong power and unique appearance design is favored by the majority of customers.
5. Applications for indoor and outdoor: KTV, Entertainment club, Stadium, Conference room etc.
| MODEL NO. | KB1200D |
| 8Ω Stereo Output Power | 4×1000W |
4Ω Stereo Output Power | 4×1500W |
8Ω Bridged watts | 2×3000W |
Output Circuit | H |
Height | 3U |
Frequency response | 5Hz-50KHz+/-0.5dB |
THD+N | <0.05%@8Ohm 1/3Po |
S/N Ratio | >102dB |
Slew Ratio | 40V/u S |
Damping factor | >400 |
Crosstalk | >65dB@8Ohm 1KHz |
Input sensitivity | 0.775V/1.0V/1.4V |
Input impedance | 20KOhm(Balance)/10KOhm(Unbalance) |
Input connector | Male XLR,Female XLR |
Output connector | Binding posts, Speakon |
Front panel control | AC Power Switch, LED(Protect,Clip ,Signal, Active),4 channels volume |
Rear panel control | Input Mode Switch: Stereo/Parallel/Bridge, Sensitivity |
Cooling | Variable Speed Fans,Front-To-Rear Airflow |
Dimension | 640mm * 480mm * 135mm |
Net weight | 38.85 kg |
Gross weight | 41.95 kg |
Packing dimension | 715mm * 555mm * 185mm |
