1. Based on the sound and performance of transistor power amplifiers, KD series has excellent signal conversion characteristics.
2. Extreamly small THD and IMD provide us pure and natural sound quality.
3. 2 channels 2U unique class D circuit along with toroidal transformer design provide stable performance.
4. Perfect circuit protection design: Soft start protection, overheat protection, short circuit protection, mute protection, DC protection, limiting protection etc.
5. With cost-effective, highly reliable and unique high-grade design appearance is favored by the majority of customers.
| MODEL NO. | KD1000 | KD1300 | KD1500 |
| 8Ω Stereo Output Power | 1000W | 1300W | 1500W |
4Ω Stereo Output Power | 1600W | 2200W | 2500W |
8Ω Bridge watts | 2900W | 3800W | 4400W |
Output circuit | D | ||
Power requirement | AC220V50Hz | ||
Frequency response | +/-0.5DB, 20Hz-20KHz | ||
THD | ≤0.05% Rated Power@8Ω 1KHZ | ||
IMD | ≤0.01% Rated Power@8Ω | ||
Slew Rate | 60V/μs | ||
S/N rate | 105dB | ||
Damping factor | 550:1 | ||
Input sensitivity | 0.77V, 1.0V, 32dB | ||
Input impedance | 10K/20K ohms | ||
Input rejection ratio | ≤-75dB | ||
Crosstalk | ≤-70dB | ||
Front panel LED | Active, Protect, Signal, Clip | ||
Dimension | 487mm X 370mm X 90mm | ||
Net weight (KG) | 17.35 KG | 17.85 KG | 18.35 KG |
Gross weight (KG) | 19.15 KG | 19.65 KG | 20.30 KG |
Packaging Dimension | 555mm X 460mm X 150mm | ||
1. Based on the sound and performance of transistor power amplifiers, KD series has excellent signal conversion characteristics.
2. Extreamly small THD and IMD provide us pure and natural sound quality.
3. 2 channels 2U unique class D circuit along with toroidal transformer design provide stable performance.
4. Perfect circuit protection design: Soft start protection, overheat protection, short circuit protection, mute protection, DC protection, limiting protection etc.
5. With cost-effective, highly reliable and unique high-grade design appearance is favored by the majority of customers.
| MODEL NO. | KD1000 | KD1300 | KD1500 |
| 8Ω Stereo Output Power | 1000W | 1300W | 1500W |
4Ω Stereo Output Power | 1600W | 2200W | 2500W |
8Ω Bridge watts | 2900W | 3800W | 4400W |
Output circuit | D | ||
Power requirement | AC220V50Hz | ||
Frequency response | +/-0.5DB, 20Hz-20KHz | ||
THD | ≤0.05% Rated Power@8Ω 1KHZ | ||
IMD | ≤0.01% Rated Power@8Ω | ||
Slew Rate | 60V/μs | ||
S/N rate | 105dB | ||
Damping factor | 550:1 | ||
Input sensitivity | 0.77V, 1.0V, 32dB | ||
Input impedance | 10K/20K ohms | ||
Input rejection ratio | ≤-75dB | ||
Crosstalk | ≤-70dB | ||
Front panel LED | Active, Protect, Signal, Clip | ||
Dimension | 487mm X 370mm X 90mm | ||
Net weight (KG) | 17.35 KG | 17.85 KG | 18.35 KG |
Gross weight (KG) | 19.15 KG | 19.65 KG | 20.30 KG |
Packaging Dimension | 555mm X 460mm X 150mm | ||
