1.KL series tradition power amplifier have excellent continuous output capacity and provide us traditional excellent sound quality.
2. 2 channels 2U high-performance and multi-function design.
3. Perfect circuit protection design: power-on buffer, overheating protection, short circuit protection, pressure limit protection, over current protection, over load protection, output DC protection.
4. With cost-effective, highly reliable and unique high-grade design appearance is favored by the majority of customers.
5. Applications for indoor and outdoor: Entertainment or multimedia.
MODEL NO. | KL500B | KL700B | KL1100B | ||
8Ω Stereo Output Power | 500W | 700W | 1100W | ||
4Ω Stereo Output Power | 750W | 1000W | 1600W | ||
8Ω Bridged watts | 1500W | 2000W | 3000W | ||
Output Circuit | AB | H | H | ||
Height | 2U | ||||
Frequency response | 10Hz-20KHz | ||||
THD+N | <0.1% | ||||
S/N Ratio | ≥100dB | ||||
Damping factor | >300 | ||||
Input sensitivity | 0.775V / 1.0V / 1.4V | ||||
Input impedance | |||||
Input connector | Convex / concave terminal XLR | ||||
Output connector | Binding posts, Speakon | ||||
Cooling | Variable Speed Fans,Front-To-Rear Airflow | ||||
Dimension | 480mm * 455mm * 90mm | ||||
Net weight | 19.80 KG | 20.30 KG | 20.80 KG | ||
Gross weight | 22.90 KG | 23.40 KG | 23.90 KG | ||
Packing dimension | 570mm * 560mm * 160mm | ||||
1.KL series tradition power amplifier have excellent continuous output capacity and provide us traditional excellent sound quality.
2. 2 channels 2U high-performance and multi-function design.
3. Perfect circuit protection design: power-on buffer, overheating protection, short circuit protection, pressure limit protection, over current protection, over load protection, output DC protection.
4. With cost-effective, highly reliable and unique high-grade design appearance is favored by the majority of customers.
5. Applications for indoor and outdoor: Entertainment or multimedia.
MODEL NO. | KL500B | KL700B | KL1100B | ||
8Ω Stereo Output Power | 500W | 700W | 1100W | ||
4Ω Stereo Output Power | 750W | 1000W | 1600W | ||
8Ω Bridged watts | 1500W | 2000W | 3000W | ||
Output Circuit | AB | H | H | ||
Height | 2U | ||||
Frequency response | 10Hz-20KHz | ||||
THD+N | <0.1% | ||||
S/N Ratio | ≥100dB | ||||
Damping factor | >300 | ||||
Input sensitivity | 0.775V / 1.0V / 1.4V | ||||
Input impedance | |||||
Input connector | Convex / concave terminal XLR | ||||
Output connector | Binding posts, Speakon | ||||
Cooling | Variable Speed Fans,Front-To-Rear Airflow | ||||
Dimension | 480mm * 455mm * 90mm | ||||
Net weight | 19.80 KG | 20.30 KG | 20.80 KG | ||
Gross weight | 22.90 KG | 23.40 KG | 23.90 KG | ||
Packing dimension | 570mm * 560mm * 160mm | ||||
