| 2 通道 | 4 通道 | |||||
| 产品型号 | DG210 | DG213 | DG215 | DG410 | DG413 | DG415 |
| 8Ω 立体声输出功率 | 1000W | 1300W | 1500W | 1000W | 1300W | 1500W |
| 4Ω 立体声输出功率 | 1800W | 2350W | 2700W | 1800W | 2350W | 2700W |
| ** 2Ω 立体声输出功率 | 2520W | 3300W | 3750W | 2520W | 3300W | 3750W |
| 8Ω桥接 | 3600W | 4700W | 5400W | 3600W | 4700W | 5400W |
| ** 4Ω桥接 | 5000W | 6600W | 7500W | 5000W | 6600W | 7500W |
| 输出线路 | D | |||||
| 高度 | 2U | |||||
| 频响 | 5Hz-20kHz,+0/-1dB | |||||
| 总谐波失真 | <0.05%,20Hz-20kHz | |||||
| 转换速率 | 20 V/µs | |||||
| 阻尼系数 | >500 (10Hz-400Hz, 8ohm) | |||||
| 信噪比 | >110dB | |||||
| 输入阻抗 | 20KQ(Balance)/10KQ2(Unbalance) | |||||
| 增益选择 | 20dB/23dB/26dB/29dB/32dB/35dB/38DB/41dB | |||||
| 输入接口 | XLR | |||||
| 输出接口 | Speakon | |||||
| 前板控制 | AC Power Switch, LED( ACT / SIG / CLIP / PRO ), 2 channels volume | |||||
| 后板控制 | Input Mode Switch: STEREO / BRIDGE / PARALLEL / GAIN | |||||
| 机身尺寸 | 483mmx90mmx320mm | |||||
| 2 通道 | 4 通道 | |||||
| 产品型号 | DG210 | DG213 | DG215 | DG410 | DG413 | DG415 |
| 8Ω 立体声输出功率 | 1000W | 1300W | 1500W | 1000W | 1300W | 1500W |
| 4Ω 立体声输出功率 | 1800W | 2350W | 2700W | 1800W | 2350W | 2700W |
| ** 2Ω 立体声输出功率 | 2520W | 3300W | 3750W | 2520W | 3300W | 3750W |
| 8Ω桥接 | 3600W | 4700W | 5400W | 3600W | 4700W | 5400W |
| ** 4Ω桥接 | 5000W | 6600W | 7500W | 5000W | 6600W | 7500W |
| 输出线路 | D | |||||
| 高度 | 2U | |||||
| 频响 | 5Hz-20kHz,+0/-1dB | |||||
| 总谐波失真 | <0.05%,20Hz-20kHz | |||||
| 转换速率 | 20 V/µs | |||||
| 阻尼系数 | >500 (10Hz-400Hz, 8ohm) | |||||
| 信噪比 | >110dB | |||||
| 输入阻抗 | 20KQ(Balance)/10KQ2(Unbalance) | |||||
| 增益选择 | 20dB/23dB/26dB/29dB/32dB/35dB/38DB/41dB | |||||
| 输入接口 | XLR | |||||
| 输出接口 | Speakon | |||||
| 前板控制 | AC Power Switch, LED( ACT / SIG / CLIP / PRO ), 2 channels volume | |||||
| 后板控制 | Input Mode Switch: STEREO / BRIDGE / PARALLEL / GAIN | |||||
| 机身尺寸 | 483mmx90mmx320mm | |||||
